1986 Charvel Imports
1987 Charvel Imports
1988 charvel
1989 charvel

Charvel Fort Worth Made in Japan Charvels

Import Charvel Guitars - 1986 Made in Japan Charvels
Charvel Model 1
Charvel Model 1
General Specifications:

Tremolo: Traditional 3-spring Fulcrum

Body Composition:
Basswood

Neck Fingerboard Composition:
RockMaple/Quarter-Sawn
Maple

Machine Heads:
Jackson SG38-07B

Fingerboard Nut Comosition:
Phenolic

Fret Wire:
Hardness - Rockwell C6/Brinell 171
Size - .118 x .114 x .51 x .37
Composition - 18% Nickel Silver

Finish Options:
Black, Red

Control Functions:
One Volume

Pickup Specifications:
Model Number: J90C (One)
Description: Ultra high output distortion
class,accentuated low frequency pickup
with ceramic magnets for
"clearer" distortion.
Sr.(in K Hz): 4.88
Z (@Sr in MOhms): 5.6
Inductance (in Henries): 9.8
Q (@Sr): 18.8
Output Level (@ Sr): +51.1dB
Magnetic Structure: Ceramic
Resistance (in KOhms): 15.93
Charvel Model 1a
Charvel Model 1A
General Specifications:

Tremolo: Traditional 3-spring Fulcrum

Body Composition:
Basswood

Neck Fingerboard Composition:
RockMaple/Quarter-Sawn
Maple

Machine Heads:
Jackson SG38-07B

Fingerboard Nut Comosition:
Phenolic

Fret Wire:
Hardness - Rockwell C6/Brinell 171
Size - .118 x .114 x .51 x .37
Composition - 18% Nickel Silver

Finish Options:
Black, Red

Control Functions:
One Volume, One Tone, Type One 5 way switch
Pickup Specifications:
Model Number:J100 (three)
Description:Magnetically-Corrected, Vintage
Type Single Coil
Sr.(in K Hz):6.10
Z (@Sr in MOhms):1.7
Inductance (in Henries):2.6
Q (@Sr):16.7
Output Level (@ Sr):+48.9dB
Magnetic Structure:Alnico V
Resistance (in KOhms):6.10
Charvel Model 2
Charvel Model 2
General Specifications:

Tremolo: Kahler® Fulcrum

Body Composition:
Basswood

Neck Fingerboard Composition:
RockMaple/Quarter-Sawn
Rosewood

Machine Heads:
Jackson SG38-07B

Fingerboard Nut Comosition:
Phenolic

Fret Wire:
Hardness - Rockwell C6/Brinell 171
Size - .118 x .114 x .51 x .37
Composition - 18% Nickel Silver

Finish Options:
Black, Pearl White, Red

Control Functions:
One Volume
Pickup Specifications:
Model Number: J90C (One)
Description: Ultra high output distortion
class,accentuated low frequency pickup
with ceramic magnets for
"clearer" distortion.
Sr.(in K Hz): 4.88
Z (@Sr in MOhms): 5.6
Inductance (in Henries): 9.8
Q (@Sr): 18.8
Output Level (@ Sr): +51.1dB
Magnetic Structure: Ceramic
Resistance (in KOhms): 15.93
Charvel Model 3
Charvel Model 3
General Specifications:

Tremolo: Kahler® Fulcrum

Body Composition:
Basswood

Neck Fingerboard Composition:
RockMaple/Quarter-Sawn
Rosewood

Machine Heads:
Jackson SG38-07B

Fingerboard Nut Comosition:
Phenolic

Fret Wire:
Hardness - Rockwell C6/Brinell 171
Size - .118 x .114 x .51 x .37
Composition - 18% Nickel Silver

Finish Options:
Black, Pearl White, Red

Control Functions:
One Volume, One Tone, Type One 5 way switch
Pickup Specifications:
Model Number: J90C (One)
Description: Ultra high output distortion
class,accentuated low frequency pickup
with ceramic magnets for
"clearer" distortion.
Sr.(in K Hz): 4.88
Z (@Sr in MOhms): 5.6
Inductance (in Henries): 9.8
Q (@Sr): 18.8
Output Level (@ Sr): +51.1dB
Magnetic Structure: Ceramic
Resistance (in KOhms): 15.93


Pickup Specifications:
Model Number:J100 (two)
Description:Magnetically-Corrected, Vintage
Type Single Coil
Sr.(in K Hz):6.10
Z (@Sr in MOhms):1.7
Inductance (in Henries):2.6
Q (@Sr):16.7
Output Level (@ Sr):+48.9dB
Magnetic Structure:Alnico V
Resistance (in KOhms):6.10
Charvel Model 3a
Charvel Model 3A
General Specifications:

Tremolo: Kahler® Fulcrum

Body Composition:
Basswood

Neck Fingerboard Composition:
RockMaple/Quarter-Sawn
Rosewood

Machine Heads:
Jackson SG38-07B

Fingerboard Nut Comosition:
Phenolic

Fret Wire:
Hardness - Rockwell C6/Brinell 171
Size - .118 x .114 x .51 x .37
Composition - 18% Nickel Silver

Finish Options:
Black, Pearl White, Red

Control Functions:
One Volume, One Tone, Type Two 5 way switch
Pickup Specifications:
Model Number: J80C (Two)
Description: High Output Distortion
Class,humbucking with Ceramic
Magnets for accentuated upper hormonics
"clearer" distortion.
Sr.(in K Hz): 5.40
Z (@Sr in MOhms): 4.7
Inductance (in Henries):7.3
Q (@Sr): 19.1
Output Level (@ Sr): +51.2dB
Magnetic Structure: Ceramic
Resistance (in KOhms): 13.00
Charvel Model 4
Charvel Model 4
General Specifications:

Tremolo: Kahler® Standard

Body Composition:
Basswood

Neck Fingerboard Composition:
RockMaple/Quarter-Sawn
Rosewood

Machine Heads:
Jackson SG38-07B

Fingerboard Nut Comosition:
Phenolic

Fret Wire:
Hardness - Rockwell C6/Brinell 171
Size - .118 x .114 x .51 x .37
Composition - 18% Nickel Silver

Finish Options:
Black, Cobalt Blue, Red, Pearl White Black Cherry

Control Functions:
One Volume, One Tone, Jackson Pre-Amp with Mid Boost, Three 2-way mMini-Toggles
Pickup Specifications:
Model Number: J200 (two)
Description: Dual Coil, Bi-level
Humbucking designed for use with
active circuitry.
"clearer" distortion.
Sr.(in K Hz): 9.90
Z (@Sr in MOhms): 1.8
Inductance (in Henries):2.4
Q (@Sr): 12.6
Output Level (@ Sr): +44.1dB
Magnetic Structure: Alnico V
Resistance (in KOhms): 11.65

Pickup Specifications:
Model Number: J50BC (one)
Description: High Frequency Bridge
Position Humbucking. Designed for use
with active circuitry.
Sr.(in K Hz): 6.58
Z (@Sr in MOhms): 5.9
Inductance (in Henries):5.3
Q (@Sr): 2.64
Output Level (@ Sr): +56.4dB
Magnetic Structure: Ceramic
Resistance (in KOhms): 8.58
Charvel Model 5
Charvel Model 5
General Specifications:

Tremolo: Kahler® Standard

Body Composition:
Poplar

Neck Fingerboard Composition:
RockMaple through Body Neck/Quarter-Sawn Rosewood

Machine Heads:
Jackson SG38-07B

Fingerboard Nut Comosition:
Phenolic

Fret Wire:
Hardness - Rockwell C6/Brinell 171
Size - .118 x .114 x .51 x .37
Composition - 18% Nickel Silver

Finish Options:
Cobalt Blue, Red, Black Cherry, Pearl White,Black

Control Functions:
One Volume, One Tone, Jackson Pre-Amp with Mid Boost, Type Two 5-way Switch
Pickup Specifications:
Model Number: J80C (Two)
Description: High Output Distortion
Class,humbucking with Ceramic
Magnets for accentuated upper hormonics
"clearer" distortion.
Sr.(in K Hz): 5.40
Z (@Sr in MOhms): 4.7
Inductance (in Henries):7.3
Q (@Sr): 19.1
Output Level (@ Sr): +51.2dB
Magnetic Structure: Ceramic
Resistance (in KOhms): 13.00
Charvel Model 6
Charvel Model 6
General Specifications:

Tremolo: Kahler® Standard

Body Composition:
Poplar

Neck Fingerboard Composition:
RockMaple through Body Neck/Quarter-Sawn Rosewood

Machine Heads:
Jackson SG38-07B

Fingerboard Nut Comosition:
Phenolic

Fret Wire:
Hardness - Rockwell C6/Brinell 171
Size - .118 x .114 x .51 x .37
Composition - 18% Nickel Silver

Finish Options:
Cobalt Blue, Black Cherry, Red, Pearl White,Black

Control Functions:
One Volume, One Tone, Jackson Pre-Amp with Mid Boost, Three 2-way mMini-Toggles
Pickup Specifications:
Model Number: J200 (two)
Description: Dual Coil, Bi-level
Humbucking designed for use with
active circuitry.
"clearer" distortion.
Sr.(in K Hz): 9.90
Z (@Sr in MOhms): 1.8
Inductance (in Henries):2.4
Q (@Sr): 12.6
Output Level (@ Sr): +44.1dB
Magnetic Structure: Alnico V
Resistance (in KOhms): 11.65

Pickup Specifications:
Model Number: J50BC (one)
Description: High Frequency Bridge
Position Humbucking. Designed for use
with active circuitry.
Sr.(in K Hz): 6.58
Z (@Sr in MOhms): 5.9
Inductance (in Henries):5.3
Q (@Sr): 2.64
Output Level (@ Sr): +56.4dB
Magnetic Structure: Ceramic
Resistance (in KOhms): 8.58
